The Plastic Flakes Mill Pulverizer Machine by SEVENSTARS MACHINERY is a versatile and efficient tool to crush and grind plastic flakes and LLDPE granules. It is a must-have equipment for the plastic industry to transform waste plastic into useful and profitable materials.
The machine is equipped with a powerful motor that delivers high-speed rotation to the blades, which shred and cut the plastic into tiny flakes. These flakes then pass through the sieve, where the correct size granules are separated and collected in a container.
One of the benefits of this machine is its ability to produce uniform and consistent plastic granules. This is achieved through its sharp blades and precise grinding mechanism, which ensures that the size and shape of the granules are consistent throughout the process.
Another advantage of the Plastic Flakes Mill Pulverizer Machine is its durability and ease of maintenance. The machine is made from high-grade materials that are resistant to wear and corrosion, ensuring that it can withstand heavy and frequent use. The blades and sieve can also be easily removed and cleaned, making it easy to maintain and prolong the machine's lifespan.
Additionally, the machine is designed with safety in mind. It features a safety switch that automatically shuts off the machine in case of an emergency or malfunction. This ensures that the users and the machine are always protected from harm.
Finally, the Plastic Flakes Mill Pulverizer Machine by SEVENSTARS MACHINERY is also user-friendly. Its compact and lightweight design allows for easy movement and storage, and it is easy to operate even for those with limited technical experience. The controls are simple and easy to navigate, and the machine can be started and stopped with a click of a button.
The Plastic Flakes Mill Pulverizer Machine by SEVENSTARS MACHINERY is an excellent investment for any plastic business looking to produce high-quality and consistent plastic granules. Its powerful motor, precise grinding mechanism, and easy maintenance make it a valuable addition to any plastic processing line
Plastic flakes Mill Pulverizer Machine /Plastic LLDPE granule Pulverizing grinding Machine
Specifications
1. high capacity
2. Working stably
3. Lower energy consumption
It is applied for PVC, PE, LDPE, LLDPE, ABS, EVA, PS, PET and rubber
components:
1. Grinding room
2. Main motor
3. Wind-sending pipeline
4. Hopper
5. Shaking feeder
6. Rotundity vibrating sieve
7. Cyclone wind butterfly valve
8. Cyclone separater
9. Blower
10. Electrical control cabinet
11. Dust catcher
Features of miller grinder:
1. The machine is adapt for heat-sensitive material processing by circulating water cooling
2. The machine is using two grind disc to smash material. Collision two disc and change input material into powder. Without sieve.
3. The disc is made of wear-resistant steel, which is through heat treatment.
4. High tight-compact, small size, maintenance should be happen before opening cover. All-sealed, dust-free spill.
5. The machine is equipped with wind blow device to ensure cool average fast cooling characteristic
6. The machine is equipped with Vibra sieve which can select material according to diameter of material
7. Equipped with dust-free device to decrease dust
Model |
|
SMF-380 |
SMF-450 |
SMF-500 |
SMF-600 |
SMF-800 |
|
|
|
|
Blade
diameter |
|
380mm |
450mm |
500mm |
600mm |
800mm |
|
|
|
|
Lade disk
quantity |
|
2pcs |
2pcs |
2pcs |
2pcs |
2pcs |
|
|
|
|
Rotated
speed |
|
4500rpm |
4500rpm |
4500rpm |
4200rpm |
3700rpm |
|
|
|
|
Power |
main motor |
30Kw |
30Kw |
37Kw |
37Kw |
45Kw |
|
|
|
|
|
|
blower |
3Kw |
4Kw |
3Kw |
4Kw |
5.5Kw |
|
|
|
|
Shaker size |
|
800mm |
800mm |
800mm |
1000mm |
1200mm |
|
|
|
|
Output size |
|
10-100 mesh 140μm-1400μm |
|
|
|
|
Cooling type |
|
Air and Water |
|
|
|
|
Capacity
For 30mesh |
|
PVC: 200kg |
PVC: 250kg |
PVC: 250kg |
PVC: 350kg |
PVC: 500kg |
|
|
|
|
|
|
P E: 150kg |
P E: 180kg |
P E: 200kg |
P E:250kg |
P E: 300kg |
|
|
|
|
|
P P:70kg |
P P: 80kg |
P P: 100kg |
P P: 160kg |
P P: 200kg |
|
|
|
Dimensions
mm |
|
2500x2000x3000 |
2600x2100x3000 |
2600x2100x3000 |
2800x2300x3000 |
3200x2800x3200 |
|
|
|
|
